nt, of the headcylinder. The mainspring, compressed by the recoil, pushes forwardthe breech block through the medium of a stirrup which connects thetwo pieces. The knee lowers itself half-way, at the same time communi-cating its movement to the receiver and to the barrel, while the firing… … 902. ARTIFICIAL ANKLE. Thespring, B, lifts the heel for the forwardmovement of the foot; the pressure ofthe body holds the foot in contact withthe ground at the forward movement ofthe body. The motion is hmited bythe angular space between the solidbearings. MISCELLANEOUS DEVICES. 353 903.…
