Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, N. W. Henley Publishing · leaf 356

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1914, leaf 356
s appropriate recess in thesocket in the foot, so as to prevent vibrationin a horizontal plane, while leaving thejoint free for motion in vertical planes, asdescribed. The elastic straps, a, b (3), areproportioned as to length and strength, and afford a means of attach-ing the suspensory yoke (4),… … 903 A. ONE-MANCROSSCUT SAW. D^ The illustration ^|/1 LJ— j shows how to rig up a large crosscut saw tocut large logs withoutthe aid of another per-The opposite end of the saw is kept from digging too deeplythe wood by a rope run over two pulleys on posts and aweight tied to its end. The weight…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
