Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, N. W. Henley Publishing · leaf 42

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1914, leaf 42
than 47. THERMOSTAT. For an incubator. A coilof zinc and steel ribbonfastened together by rivetsor solder is fixed at its cen-ter end to a block in theincubator chamber and at-tached by a lever to adamper and to a lever onthe wick gear, and controlsboth air inlet and flame.The zinc should be… … balancing lever and connections ; A, air inlet cylinder; B, lamp chim-ney, all of sheet iron ; O, damper rod ; D, wick rod. 40 MEASUREMENT OF POWER, SPRINGS.

Mechanical movements
