Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, N. W. Henley Publishing · leaf 52

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1914, leaf 52
Max. load. Deflection. Flexibility. p_S-D316R 2RSL ~ D G 32 P R^ L F_ ttGD^ F 2S LR~ GD G, modulus. 72A. TRACTION DYNAMOMETER. The drawbar puU of anymotor vehicle is determined by means of some form of traction dyna- Gauge To Power … mometer. This instrument is placed between the source of power ordrawbar of the vehicle and some immovable body, such as a large tree.The vehicle is started and the maximum amount of pull is indicatedin pounds upon the gage just before the vehicle driving-wheels slip orthe engine stops. This…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
