Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, N. W. Henley Publishing · leaf 63

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1914, leaf 63
steam. The air and steamare thoroughly mixed in the shell of the blow-er before the blast is delivered into the ashpit. It makes very little noise in operation. 99. Section, showing ring and jets. 100. COAL DUST FEEDING APPARA-TUS. A revolving steel brush carries the coaldust into the furnace with… … GENERATION OF POWER, STEAM. 6l loi. COAL DUST BURNER. The vertical tube, a, for intro-ducing the air serves as a pivot to the system, which comprises : i, themovable jacket, b, to which are bolted the primary air conduit, c, andthe secondary air conduit, d; 2, the hopper, e, supported by the…
