Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, N. W. Henley Publishing · leaf 67

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1914, leaf 67
brick. J, a cupigniting. Air pres- sure, 25pounds. to 30 … 116. LIQUID FUEL BURNER. Cup grate type, operated by natural draught of thechimney. The heat of the furnace heats theinner edge of the cups or troughs, vaporizes theoil, which mixes with the air in draught. Theoil is fed to the upper trough and overflows tothe next trough, and so on for as many…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
