Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 105

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 105
235. NOVEL REDUCING VALVE. Holly type, having a large area and lap ofa flat valve disk. The relative difference ofpressure is regulated by the free hangingweights under the disk, while excessive backpressure tends to close the valve by pressureon the large area of the back of the disk. The wheel…

Mechanical movements
