Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 107

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 107
243. FLEXIBLE BALL JOINT. The space between the ball and shell is filled withan elastic lubricated packing held in place byan annular follower and springs. 244. BALANCED EXPANSION JOINT for steam pipesSmith pat. Referring to the cut, it will be noticed that the inner tube has an increased…

Mechanical movements
