Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 120

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 120
EXPLOSIVE MOTOR POWER AND APPLIANCES. 115 … 269. ALCO-VAPOR BOILERand three-cylinder engine. Alcoholof low grade is injected into the pipeboiler and converted into vapor un-der pressure by the heat of part ofthe vapor burned under the boiler.The three cylinders are single actingon a single crank. Casing of boileris removed to show its…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
