Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 122

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 122
LINE ATOMIZER AND VAPORIZER. Hay type. The exhaust is used forheating the walls of the va-porizing chamber by trav-ersing the annular cham-ber e. A fan, h, is revolvedon the spindle, J, by the in-rushing air and gasolinethrough the valve E, whichalso covers the gasoline in-lets on the face of the… … 275- SOOT-PROOF SPARKING PLUG. For gas engine. Merger type. An annular pro-jection on the end of the por-celain insulator extends the insu-lating surface and prevents shortcircuiting of the electric spark.

Mechanical movements
