Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 128

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 128
change speed gearing is mounted in an extension of the engine crankcase, which insures that all parts will be in line with the engine crank-shaft. An engine of this character is usually supported by threepoints only, one at the front and one on each side of the fly-wheelcase. This permits the frame… … 282. WAVE MO-TORS. Waves oper-ating a hydraulic ram. 283. Waves oper-ating swinging levers. 284. Waves push-ing a vertical surface. 285. Waves liftinga float. 286. Waves swing-ing a hinged bladeanchored on the bot-tom.

Mechanical movements
