Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 131

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 131
The revolvingwater on eachside near the shaft in curvedchannels, and discharges throughopenings in the periphery of thedisk opposite to a continued slotin the casing. A corrugated clos-ure of the shell and disk near theshaft prevents back flow of thewater escaping over the peripheryof the disk,… … frame on piles, or on floats in a stream, shows increased power by thelarge number of submerged buckets. 295. FLOATING MOTOR FOR RIVERS. A wheel of thewindmill type is hung within a bell-mouthed case, which may be

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
