Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 133

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 133
to match the buckets. The water flow is governed by the opening orclosing of a sector slide valve controlled by a fly governor.300. Elevation, showing position of nozzle and buckets. 128 HYDRAULIC POWER AND APPLIANCES. … 301. MULTINOZZLE TURBINEor impact wheel. German type. Thenozzles are in a segment and closed forregulation of power by a sliding seg-ment on the outside, operated by apinion with a controlling wheel outsidethe case. The water strikes the face ofthe buckets and is discharged at theirsides. 302.…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
