Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 136

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 136
HYDRAULIC POWER AND APPLIANCES. 131 312. WATER-PRESSURE REGULATOR. Used in high-pressure service pipes. The diaphragm x and plunger s operate the valve c through the lever r>and the relative pressures areregulated by the movable ful-crum e. #, high-pressure pipe;b, low-pressure pipe ; v,… … <f^=*> \M =s\ 313. VENTURI TUBE AND MEASURINGMETER. The differential velocity of the water in themain pipe and in the throat of the double conical tubeproduces a differential pressure in the small tubes withtheir mouths turned in opposite directions, which is usedfor registering the amount of…
