Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 137

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 137
ta kj 315. UNIFORM FLOW OF WATER from a variable tank head.a, a tank with variable head of water;d, small tank with float connected tosectored arm/ and to the conical valveh in the tank a. When well-adjustedwill give a uniform head in d for theoutlet at e. … 316. NOVEL SPRAYING NOZZLE for cooling water by contact of the spray waterwith the surrounding air. The apertures inthe concave cap give a slightly spiral directionto the jets, which gives them a rotary motionand disintegrates the water into a fine spray. 317. HYDRAULIC PRESS for making tin-lined…

Mechanical movements
