Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 140

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 140
, as shown inthe cut, 326, inserting it and push-ing it down in the bottom of thewell, 328, and boring out the sandwith a sand auger, 327. A drive-strainer tube may also be drivenand the sand drawn by an auger.Strainer points are also used anddisconnected near the bottom ofthe well. The supply of… … of chamber and held open by the lever and weight L, with its move-ment adjusted by the springs above and below the lever. D, discharge 136 HYDRAULIC POWER AND APPLIANCES. valve. G, a chamber with elastic heads or diaphragms of thin cor-rugated metal, for an air chamber and to prevent hammer. K.…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
