The particular featureof this fan is in thenarrow curvedblades set in theperiphery of thewheel and close to-gether, which pre-vents local eddiesand greatly in-creases the effi-ciency of the fan.Davidson patent. 341. Section showing shaft and bracing to the blade drum. … 342. AERIAL TOP. A small windmill madeof any convenient material that is light. A y.tem atthe center to drop into the ring handle, on which thestring is wound. The rapid rotation made by quicklypulling the string will force the top to a height of 150to 200 feet. There should be a ring ol brass…
