Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 149

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 149
hen it blows per-pendicularly upon the axle, thus permitting(owing to the impossibility of reducing thesurfaces) of threescore days more workper year being obtained than can be withother mills so claimed in proportion to thework of the old Holland mills. 356. A KANSAS WINDMILL.Made with canvas… … AIR-POWER MOTORS AND APPLIANCES. 145 357. SAILING WAGON. Across the wide forward end of thetriangular frame extends an axle to which wheels are journaled. The short axle of the rear wheels is piv-oted by a kingbolt to the narrowend of the frame. To the short axleis attached a gear wheel into…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
