Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 150

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 150
aft is a handwheel or tiller, bymeans of which the wagon may beguided. The speed of the wagon isregulated by brakes upon the front wheels, connected with an uprightlever pivoted in the middle part of the frame and provided at its upperend with a crosshead, so that it can be operated either with the… … 358. SAIL-RIGGED MERRY-GO-ROUND, St. Malo, France.

Mechanical movements
