Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 160

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 160
amylic alco-hol, after care has been taken to fill thereservoir, P, with oil after unscrewing theplug A. The alcohol is lighted, and assoon as the worm is hot the cock isopened, the jet takes fire, and the ap-paratus is ready for use. Upon the stovethere may be placed either a cast-iron potin which… … i56 GAS AND AIR-GAS DEVICES, ETC. WORKING STAGE 377. PRODUCER GAS GENERATOR. German type. A,door for feeding coke to the furnace B and for blowing up. C, fire- s brick walls of the furnace. E, air inlet for heating thefurnace of the generator.F and G, gas blow-off pipe5interchangeable to reversethe…
