Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 165

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 165
385. GASOLINE TORCH. Gasoline forcedinto a small retort, previously heated by firing asmall quantity of gasoline in the cup below, is vapor-ized and issues through the perforated top of theretort in a brilliant light. About 3 feet below thereservoir for the burner is sufficient for the… … 386. KEROSENE SOLDERINGFURNACE. Air is compressed in theoil tank by the rubber bulb by which theoil under pressure is forced through aneedle valve to a vaporizing retort and bya Bunsen-burner jet is mixed with airand forced into the burner tube, whichis perforated with small holes that feedthe…

Mechanical movements
