Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 165

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 165
lve to a vaporizing retort and bya Bunsen-burner jet is mixed with airand forced into the burner tube, whichis perforated with small holes that feedthe heating flame. 387. KEROSENE OIL BURNER for stoves. The coil of iron pipe in the box is the vaporizer, terminating in the cross pipe and two jet… … GAS AND AIR-GAS DEVICES, ETC. 161 388. KEROSENE COOK STOVE. National Oil Heating Co.type. Air is compressed in the oil tank above the oil, which drives the oil to a vaporizer in the burner pan,where the oil is vaporized and forcedthrough a combination air jet to thechamber of the burner box, which…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
