Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 179

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 179
consists of a firebrick casing A, with a magnesia lining B. The shape is conical, and atthe bottom the furnace is contracted toform a hearth for the fused carbide.The tapping hole is at the bottom ofthis contracted part. The lower elec-trode is a carbon plate, and the upperelectrode a massive… … 420. TANDEM WORM-GEAR ELECTRIC ELEVATOR. Siegel-Cooper store, N. Y. Hindley type. Geared 46 to 1 for a speed of the car of 100 feet per min-ute with a motor speed of470 revolutions per minute.Efficiency from current tocar service 70 per cent.The double worm and in-terlocking gears contributeto the…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
