Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 190

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 190
prolongation of the axes of the magnet (shown by the dotted line, X X) passes throughit. The watch isvibrated around anaxis passing throughC and at right anglesto X X. By this operation the watch is successively brought into thepositions A and B, in all positions around the hour circle. A few…

Mechanical movements
