ear, an upright shaft journaledin the sleeve or hollow post, andprovided with a beveled gear intermeshed with that on the propellershaft, an electric motor comprising a rotary armature fixed directlyon the upright shaft, a source of electric energy, a hand grasp pivotallyconnected to the outer end… … M ELECTRIC POWER AND DEVICES. 450F. ELECTRICALLY OPERATED VALVE. The accom-panying cut shows a valve which is operated by the action of an electric currentflowingthrough thesolenoidmounted overthe pipe shown.The action isto draw downthe iron coreand press downthe curvedlever whichopens the…
