Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 200

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 200
blade isprecisely alike, so that if one should bebroken a duplicate could be readilyfitted. A collar is secured upon the shaft,and the inner legs of the blades bearfirmly against it. The sleeve, B, keepsthe legs of the blades at the properdistance apart, and the collar, C, andnut secures all in… … I96 NAVIGATION, VESSELS, MARINE APPLIANCES, ETC.

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
