Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 201

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 201
93. Blade and crank connection. 489. FEATHERINGBLADE PROPELLER.A foot-power propellerwith paddle blades tohang over the sides at thestern, or may be placed inan extension at the stern,as shown in the cuts.The longest movement ofthe paddle is when it isimmersed, and the pad-dle being vertical, there… … 26 inches. Wheel 20 inches diameter, 30 inch pitch, with or withoutsteel wheel guard. Motor, 12 horse power. Displacement with pas-sengers, 2,000 lbs. Elevation and midship sections. 495. Sectional elevation of frame, motor and propeller. 496. Plan with lines of upper works. NAVIGATION, VESSELS,…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
