Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 207

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 207
:::. THE DRAG STEERING GEAR. Different rigs for con-structing and operating a temporary steering gear when the rudder is disabled. The float isa strong plank, so fast-ened by the rope harnessas to keep it in a verti-cal position in the sea. :::. Tackle rig froma projecting spar andcross tree. ::4-… … z

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
