Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 217

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 217
212 ROAD AND VEHICLE DEVICES, 17 I … type. 538. DUMPING WAGON.The loaded box is just overbal-anced to tip backward. A dogcatch on the drivers footboard islet go for self-tipping of the load. DIFFERENTIAL SPEED GEAR for bicycles. Eire & ToddA is the crank-axle gear wheel. C the chain wheel, working through supplementary bracket.…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
