Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 220

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 220
549. TYPES OF MOTOR BICY-CLES. The Brown. Much after the styleof the Derby, but driven by a belt from themotor pulley to a pulley attached to the rearwheel. 550. TYPES OF MOTOR BI-CYCLES. The Minerva. The motorhangs beneath the lower reach anddrives by belt over a pulley on rearwheel. Has a surface… … 551. TYPES OF MOTOR BICYCLES. The Singer. Themotor and all its appurtenances, including fuel tank, are within the rear wheel, which, with the exceptionof the controlling rods and levers, is inde-pendent of the rest of the bicycle. Themotor is hung on a fixed shaft with itscrank shaft below the…

Mechanical movements
