Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 228

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 228
servoir blows the sand into thedischarge pipe. 568. MULTIPLE PLATE FRICTIOXCLUTCH. Pattern of the main drivingshaft clutch, Brooklyn Bridge. Every otherring plate is keyed to the inner sleeve andflange; the alternate rings are keyed todriven shaft-flanged hub. A toggle, oper-ated by the collar and… … ers. 570. Steel cross-bar frame. Leafsprings under car. 571. Cast - steelbox case riveted towrought iron frame.

Mechanical movements
