Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 232

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 232
588. ROLLINGAND COM-PRESSINGSTEEL CARWHEELS. Fow-ler type. Fivesmall wheel treadrolls spaced aroundthe hot car wheelare revolved andpressed to thewheel rim, re-ducing its diam-eter a half inch. Theinner form of the wheelkept true duringthe rolling by moldsclamped to each side.The small sectionshows… … 590. REVERSING CAR SEAT. A shiftingback seat actuating a foot rest when shifted, tomove into proper position to carry it out of the wayof the occupant of the seat and leave a baggagespace under the seat, while at,the same time, bythe same movement, the foot rest is properly placedfor the occupant…

Mechanical movements
