Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 235

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 235
A hp. motorcycle is mountedon a 300-lb. railwayhand-car, and the drivefrom the machine is byV-belt to a pulley on acountershaft, and thenceby chain to the frontwheels of the car. Whenriding alone, one has to carry ballast, otherwise the wheels would not hold to the track, but with two people aboard… … RAILWAY DEVICES AND APPLIANCES, ETC. 23I 599B. COALING STATION. A locomotive-coaling station thatis compact and easily operated is shown. The structure is of steel,6 feet by 16 feet in size, and stands between a car siding and thelocomotive track. Under the coal-car siding is a steel hopper…
