Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 240

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 240
GEARING AND GEAR MOTION, ETC. 235 … 607. INTERRUPTING CAM-GEAR MO-TION. B, the driver. The motion of A isfrom fast to slow or slow to fast, with a momen-tary stop as the long teeth match at C and C.The stop motion is governed by the form of thecurves of the long teeth at C and C.

Mechanical movements
