Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 258

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 258
665. WEIGHT-DRIVEN MOTOR. A gear train and winding drum for arope ; a ratchet wheel and pawl forwinding up the weight. A fly wheel,shaft, and crank gives a reciprocatingmotion to a lever or for any purpose ofmotion. :: :t::n a:t : ::*tj.: ::• :r.i. I 2Z~.~ . ~~.~.;. 1L\~Z .. ZI~.~~.ILZ Zi~ C.

Mechanical movements
