Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 26

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 26
ball bearings. To eachend of the shaft is secured an arm whose outer end is connected by alink to the crank, the crank being in advance of the arm, or precedingit in the direction of rotation, whereby the pull of the crank is impartedwith most directness during the time the crank is passing through… … 5D. USEFUL FOOT VISE. Thisshows a simple foot vise made from ablacksmiths vise in which the jaws aregood. Strap A is J^ inch by 2^2 inches.One is used on each side and bent as shown.There are four links, E, two on each side,to form a -toggle linkage. A coil spring isused to open the jaws, which are…
