Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 271

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 271
697. ELECTRIC RATCHET. The electro-magnets M, M, operated by current from a cen-tral clock, vibrate the lever L, in unison andmove the escapement wheel by the pawl D, D. A very simple device for operating the es-capement of a secondary clock from a centralstation. gj-^a^ 266 HOROLOGICAL, TIME… … 698. SOLAR AND SIDEREAL CLOCK. Firmly secured on asolid base of metal are two regulators, each having a one-second mercurial pendulum. One of the pendulums is regulatedto mean solar time and the other to sidereal time,the dial of the latter being divided into 24 hoursand that of the former into 12…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
