Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 273

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 273
end of the table, it strikes a springwhich releases a catch holding the shaft, which is thereby permitted tomake a hah turn, and its arm is correspondingly moved to raise or depressthat end of the table to which the connecting rod is attached. The ballthen runs down the table, strikes a similarly… … 702. ELECTRICAL CORRECTION OF CLOCKS. For a clock that gains some second or two per hour.Fifteen seconds before each hour the lever,D B, is attracted by the electro-magnet, A.and a pin in the arm, D, would thereuponenter and catch a tooth of the escape wheel,did the disk, M, allow the other arm of…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
