Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 274

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 274
d, is thrown out-ward by centrifugal action ; and when thethread touches one of the fixed verticalwires at the side of the clock, the momen-tum of the spherical weight causes it towind the thread around the vertical wiref/M>r\~ < *3^\ [U and stop the arm and spindle. As soon If (IvF HIJ) ll… … 20 HOROLOGICAL. TIME DEVICES. ETC. the thread winds and unwinds once more, when the arm is released, andmakes a hah revolution, when the thread is wound on the other verticalwire, and the operation just described is repeated. 705. SELF-WINDING, SYNCHRONIZING CLOCK. O. P.electric motors operated by…
