Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 28

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 28
8. QUICK COUPLING for sewer rods. Makes a smooth contin-uous rod that can not uncouple whilein use. … 9. TRANSMISSION of powerby, wire rope and anchored levers.The braced tee pieces A B, withtheir arms connected with a distantrocker by the wire W W, pivotedto the windmill frame and to thecrank rod at A, make a very effec-tive method of operating a pumpat a distance. A strong fencewire is sufficient…

Mechanical movements
