Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 282

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 282
ace.The furnace grates are on the outside, distributed for equalizing theheat which passes off through a chimney at the feed hopper end. 721. MAGNETIC METAL SEPA-RATOR. For separating iron turn-ings, filings, and chips from brass com-position or other non-magnetic material. The drum is composed of… … 278 MINING DEVICES AND APPLIANCES. 722. MAGNETIC SEPARATOR for separating iron from brassturnings, small scrap, chips, and drillings. A rod connected to the hopper swings it back andforth when the separator isin operation so as to distributethe metal on the surface ofthe drum. An adjustablegrate is…
