Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 285

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 285
e heavier portion of thegravel—the gold and ironor black sand, whichfalls into the chute, h,from the lighter portionfalling into the tailingschute *. The lattice, k, k, is simply to prevent eddy currents of air goingdown the chutes h and i. The end of the air pipe at k is open. By a suitable…

Mechanical movements
