Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 29

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 29
by dumping them off the side at places where the inclined guideboard is set … 12. I BEAM TROLLEY. A sim-ple and effective apparatus with a chaintackle for setting heavy work in lathesand moving light articles in shops. The I beam makes a most convenientoutrigger from the front of a warehouseor factor}r for the transfer of goods toand from trucks. TRANSMISSION OF POWER 25

Mechanical movements
