Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 297

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 297
761. C R A X E TRUCK. One of thehandy things in a shop or warehouse. Withwindlass chain and block two tons may be liftedand easilv wheeled over the floor. … 762. CENTRIFUGAL SEPARA-TOR. The perforated basket and loadare hung on the spindle. E is a cup-shaped pulley, inside of which is a ball-socket journal box. The step bearing, 6, a,is also a ball socket in a spherical foot, bear-ing upon a spherical base with a flangeon its rim to limit the eccentric…

Mechanical movements
