Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 297

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 297
shaft. C. that is fitted in a socket. The lower end of the shaft has a step inthe lever, F, which is pivoted to thehind leg of the stand, and extendsforward and alongside of the anvilblock. A bar, I, having a seriesof holes for fastening the lever atany point by a pin. An arm. M.is attached to the… … MILL AND FACTORY APPLIANCES AND TOOLS, ETC. 293 The hammer handle is connected to a foot lever, Q, by a cord, S ; acoiled spring is fitted, to be contracted when the hammer is forced down,for raising the hammer again. The spring bears against the head of theshaft, C, and the rod connects with the…

Mechanical movements
