Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 302

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 302
783. OIL OR GAS FIREDAir FORGE. Oil or gas enters the ato-mizer by the small pipe and is mixed atthe nozzle by a strong blast of air. Ad-ditional air jets to complete the com-bustion enter beneath the bed of the— furnace. … 784. MELTING FURNACE for brass,copper, or bronze. Operated by gas orcrude oil, and compressed air. Oil or gas is fed through the small pipe,atomized and mixed with air in the inletnozzles at the top of the cupola and the flameprojected down upon the metal. The cupolais tipped by the wheel and gear…

Mechanical movements
