that may be re-quired, by adjusting the stays in which thecutters are hung to the required angle. The central cutter, H, as will be seen,cuts into the board at a right line be-tween the side saws, and as it leads inthe cutting, the central portion of the mor-tise is cut away : the side saws, as… … 7qq. DIAMOND MILLSTONE-DRESSING MACHINE A achine for dressing millstones. The frame. A. has arms, b, b, terminating in feet, r7, which areprovided with set screws. A toolsupport. S. is pivoted to the center:: A. and is adjustable by mean- Isector. B. and slides on the arm. C.of the frame. Two disks…
