Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 336

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 336
Two 75-horse-power gasoline engines, manufactured by Fairbanks,Morse & Co., are provided. Each engine is so arranged and con-nected with the machinery that it can operate both bridges eitherjointly or separately, as desired. The operators house is constructedentirely of steel and fireproof… … frame. The bridge is 160 feet on the long span and 100 feet on theshort span. Balanced on friction rollers by counterweights and oper-ated by electric motor. Plan and elevation. BUTTONROPE SMAIN CABLE TRAVERSING

Mechanical movements
