Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 346

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 346
873. REVERSIBLE PLOW. The wheel runs in the last furrow.y, yoke handle, which turns over tothe other side at the end of a fur-row ; V, latch to fasten the handleto the beam ; /, k, clevis and chain. 874. TETHERINGlb … HOOK. The hook or fastening for tetheringor coupling animals by their bridles, etc., andfor other uses, comprises a link, c, and a hook, a,the point of which can not pass through the link.The hook has holes for the link and the fixing-staple b. The strap, s, is attached to the fasten-ing; as shown.

Mechanical movements
