Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 346

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 346
HOOK. The hook or fastening for tetheringor coupling animals by their bridles, etc., andfor other uses, comprises a link, c, and a hook, a,the point of which can not pass through the link.The hook has holes for the link and the fixing-staple b. The strap, s, is attached to the fasten-ing; as shown. … 875. FOUNTAIN WASH BOILER. The broad base of the j§j siphon collects the steam generated on the bottom of the boiler, which \ rising in the vertical pipe induces a 7-^===EE rapid flow of boiling water, creat- ~^== ing a circulation through the clothes. 876. POTATO-WASHING MACHINE, a, spiral of arms…

Mechanical movements
